Intel HD Graphics 520 (Mobile)
Architecture : Skylake
Codename : Skylake GT2
Chip : -
Core : 24
Memory : SHARED
Bus Width : 64 bit
Core Clock : 300MHz - 1000MHz
Memory Clock : 1067MHz
TDP : -
Technology : 14nm
Bus Interface : IGPU
CPU: i5 6300U
See more specification...
Thursday, 10 August 2023 10:15 | Update at 1 month ago
Hardware Benchmark Record
This table displays the scores or sequential read & write speeds (for storage types) of various synthetic benchmark applications commonly used to test hardware performance. You can click on the score column to view the submissions page by ID. At that URL, you can browse the submitted results of each application, including viewing screenshots of the benchmark results. For screenshots of benchmark results, you can click the "View" button in the screenshot column.
In total, there are 17 submissions across 17 different benchmark applications, each testing the hardware from a unique angle. This variety allows you to draw a more comprehensive conclusion about the hardware's real-world performance.
Media Gallery
A collection of photos of tested hardware. These images can help you identify the physical form, model, and variant of the hardware in question. These photos are from our own documentation, and if they are not available we may not be able to document them.
Nearby Competitors
Shows two other devices with slightly higher scores and two others with slightly lower scores on the same benchmarks. Useful to see how competitive these devices are.
3DMark - Cloud Gate
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 14993 marks | 326.7% |
| Higher | AMD Radeon Graphics Mobile (Lucienne, 384 Shaders) | 15961 marks | 347.8% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 4589 marks | 100% |
| Lower | AMD Radeon HD 6520G | 2348 marks | 51.2% |
| Lower | AMD/ATI Mobility Radeon HD 5450 | 2301 marks | 50.1% |
3DMark - Fire Strike
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | AMD Radeon Graphics Mobile (Lucienne, 384 Shaders) | 2468 marks | 370.6% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 2791 marks | 419.1% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 666 marks | 100% |
| Lower | AMD/ATI Mobility Radeon HD 5450 | 248 marks | 37.2% |
| Lower | AMD Radeon HD 7310 | 156 marks | 23.4% |
3DMark - Fire Strike (GPU)
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 2977 marks | 420.5% |
| Higher | NVIDIA GeForce MX350 | 4225 marks | 596.8% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 708 marks | 100% |
| Lower | AMD Radeon HD 7310 | 197 marks | 27.8% |
3DMark - Fire Strike Extreme
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 1264 marks | 402.5% |
| Higher | NVIDIA GeForce MX350 | 1894 marks | 603.2% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 314 marks | 100% |
| Lower | AMD Radeon HD 7310 | 78 marks | 24.8% |
| Lower | AMD/ATI Mobility Radeon HD 5450 | 76 marks | 24.2% |
3DMark - Fire Strike Ultra
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | NVIDIA GeForce MX350 | 543 marks | 352.6% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 750 marks | 487.0% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 154 marks | 100% |
3DMark - Ice Storm
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 64695 marks | 178.8% |
| Higher | NVIDIA GeForce MX350 | 75915 marks | 209.8% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 36177 marks | 100% |
| Lower | Intel HD Graphics 3000 Mobile | 29702 marks | 82.1% |
| Lower | AMD/ATI Mobility Radeon HD 5450 | 25624 marks | 70.8% |
3DMark - Ice Storm Extreme
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 50029 marks | 180.4% |
| Higher | AMD Radeon Graphics Mobile (Lucienne, 384 Shaders) | 65366 marks | 235.7% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 27733 marks | 100% |
| Lower | Intel HD Graphics 3000 Mobile | 17915 marks | 64.6% |
| Lower | AMD/ATI Mobility Radeon HD 5450 | 15735 marks | 56.7% |
3DMark - Ice Storm Unlimited
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 104282 marks | 200.2% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 138590 marks | 266.1% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 52089 marks | 100% |
| Lower | Intel HD Graphics 3000 Mobile | 29806 marks | 57.2% |
| Lower | Qualcomm Adreno 610 | 26970 marks | 51.8% |
3DMark - Night Raid
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 12386 marks | 448.6% |
| Higher | NVIDIA GeForce MX350 | 15546 marks | 563.1% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 2761 marks | 100% |
3DMark - Sky Diver
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | AMD Radeon Graphics Mobile (Lucienne, 384 Shaders) | 8990 marks | 312.5% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 10752 marks | 373.7% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 2877 marks | 100% |
| Lower | AMD Radeon HD 7310 | 762 marks | 26.5% |
3DMark - Time Spy
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | AMD Radeon Graphics Mobile (Lucienne, 384 Shaders) | 997 marks | 389.5% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 1179 marks | 460.5% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 256 marks | 100% |
3DMark - Time Spy Extreme
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 702 marks | 600.0% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 117 marks | 100% |
Geekbench4 - Compute
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 37395 points | 269.7% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 50025 points | 360.8% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 13866 points | 100% |
| Lower | Qualcomm Adreno 610 | 5037 points | 36.3% |
| Lower | IMG PowerVR Rogue GE8320 680MHz | 3284 marks | 23.7% |
Geekbench5 - Compute
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 12442 points | 362.0% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 14320 points | 416.6% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 3437 points | 100% |
| Lower | Qualcomm Adreno 610 | 453 points | 13.2% |
Geekbench6 - Compute
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Tiger Lake) | 11034 points | 387.8% |
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 12092 points | 425.0% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 2845 points | 100% |
| Lower | Qualcomm Adreno 710 | 1729 points | 60.8% |
| Lower | Qualcomm Adreno 610 | 348 points | 12.2% |
3DMark - Cloud Gate (GPU)
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 27181 marks | 483.1% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 5626 marks | 100% |
3DMark - Time Spy (GPU)
| Rank | Hardware | Score | Performance Percentage |
|---|---|---|---|
| Higher | Intel Iris Xe Graphics Mobile (80EUs, Raptor Lake) | 1324 marks | 591.1% |
| This Hardware | Intel HD Graphics 520 (Mobile) | 224 marks | 100% |
About HD Graphics 520 (Mobile)
Intel HD Graphics 520 is an integrated GPU used in 6th generation Intel Core processors (Skylake), such as the Intel Core i5-6300U found in many business laptops and ultrabooks. It has 24 Execution Units (EUs) with speeds up to 1.0 GHz, offering sufficient graphics performance for light to medium computing needs in the portable device class.
As part of the Skylake architecture, the HD Graphics 520 supports DirectX 12, OpenGL 4.5, and Vulkan 1.0, which makes it flexible enough to run a wide range of modern applications. The GPU is also equipped with hardware acceleration for H.265/HEVC video decoding, making it suitable for high-resolution video playback, including 4K content. The power efficiency of this architecture makes it ideal for use in high-mobility laptops like the Lenovo ThinkPad T470, which rely on long-lasting battery performance.
Compared to previous generations such as the Intel HD Graphics 5000 (Haswell), the HD Graphics 520 comes with improved graphics performance and better power efficiency. Although still in the entry-level GPU class, the HD 520 is capable of running light games such as League of Legends, Dota 2, and Minecraft at 720p to 1080p resolution with low to medium graphics settings. For activities such as light graphic design, multitasking, and daily office use, this GPU provides a smooth and responsive experience.
In a device like the Lenovo ThinkPad T470, the HD Graphics 520 is paired with 8GB of single-channel DDR4 RAM, which while it could still be optimized with dual-channel, is enough to support productive user activities. The Windows 10 operating system also works very well with this generation of Intel graphics drivers, which continue to receive compatibility and performance updates from Intel.
Overall, the Intel HD Graphics 520 offers integrated graphics performance that strikes a balance between power efficiency and multimedia capabilities. It is suitable for office workers, students, and business laptop users who need stability and modern technology support without the need for a discrete GPU.
Hardware Detail:
Device: Lenovo ThinkPad T470
CPU: Core i5-6300U
RAM: 8GB DDR4 Single Channel
OS: Windows 10
